M-Eye Scanner Dual Iris Scanner

Kategori: Alat Perekam E-KTP

M-EYE adalah alat pemindai iris ganda yang tangguh, portabel, dan mudah digunakan yang dapat merekam kedua iris secara bersamaan dengan akurasi dan kecepatan yang tinggi. Bisa digunakan untuk merekam data biometrik saat perekaman KTP Elektronik (E-KTP).

Berikut spesifikasi M-EYE :
*Simultaneous Capture : Dual IRIS Capture *IRIS Diameter : > 210 Pixel *Spatial Resolution : > 60 % @ 4.0 LP/mm *Pixel Resolution : > 20 Pixel/mm *Image Margins : Left & Right >= 0.5x IRIS Diameter, Top & Bottom >= 0.25x IRIS Diameter *Pixel Depth : 8 Bits/Pixel (256 Gray Level) *Imaging Wavelength : 700 - 900 nm *Frame Rate : >=10 Frames/Sec *Scan Type : Progressive *Sensor SNR : > 36 dB *Capture Mode : Auto Capture with Built-in Quality Check *Illumination : Near Infra Red (NIR) *Capture Distance : > 100mm from the Front of Camera mirror *Capture Volume (WxHxD) : 30 x 22.5 x15 mm *Exposure Time : < 33ms *Interface : USB2.0 High Speed (USB-IF Certi ed) *Operating Voltage : 5V +/- 5% *Current Consumption : Operating :- < 375 mA (Max) , Stand By :- < 160 mA (Max) *Operating Temperature : 0 to 50 °C *Operating Humidity : 10-90% RH, Non-Condensing *ESD Protection : +/-4kV (Contact Discharge), +/-8kV (Air Discharge) *Device Dimension : 185 x 145 x 62 mm *Device Weight : 0.41Kg *Biometric Data Interchange Format : ISO 19794-6 for IRIS Image, *ISO 29794-6 for image quality *EMI / EMC Compliance : CE & FCC Part 15B class B *Environmental, Health and Safety : ROHS *Safety : Exempt Group per IEC 62471:2006-07, IS13252 (Part 1) *Ingress Protection Rating : IP65 *Operating System : Windows x86 and x64, Linux
